What Is a Split System Aircon and Is It Right for Your Home?
If you want efficient heating and cooling for a single room or a defined zone, a wall-mounted split system aircon is often the best value. It’s quick to install (a standard “back-to-back” is usually simplest), quieter than portable/window units, renter/strata-friendly in many cases, and far cheaper up-front than ducted. Choose one if you need comfort in a bedroom, study, lounge, granny flat or small office.
A split system is made of two parts: a wall-mounted indoor unit (the “head”) and an outdoor condenser linked by small refrigerant pipes and control cabling. Most models in Australia are reverse-cycle heat pumps, which means they heat in winter and cool in summer using one appliance. They’re widely recommended here because reverse-cycle systems are highly efficient and suit our three climate zones under the Zoned Energy Rating Label (ZERL).
Suggested visual: simple line diagram showing indoor unit, refrigerant lines through wall → outdoor unit.
How Does a Split System Aircon Work?
Think heat pump loop in plain English:
- Indoors, the evaporator absorbs heat from room air as refrigerant evaporates.
- The compressor outside raises refrigerant pressure/temperature.
- Outside, the condenser dumps that heat to outdoor air.
- An expansion device drops the refrigerant pressure to restart the cycle.
Reverse the flow to heat your home in winter.
Because it moves heat rather than making it, a modern reverse-cycle split typically delivers about 3–6 units of heat/cool for every 1 kWh of electricity. That’s ~300–600% “efficient” in heat-pump terms.
Pro tip: On labels and spec sheets you’ll see EER/AEER (cooling efficiency) and COP/ACOP (heating efficiency). Higher is better.
Split System Aircon vs Ducted
Coverage & Zoning
- Split: Best for single rooms or defined zones (e.g., living, master, study).
- Multi-split: One outdoor + multiple indoor heads is a middle ground when you can’t run ducts or don’t have outdoor space for several condensers.
-
Ducted: Whole home solution via ceiling or under-floor ducts; can be zoned but has duct losses.
Install Complexity & Disruption
- Split: A back-to-back install (indoor and outdoor on opposite sides of the same wall) is usually fastest with the least materials. More complex runs (longer line-sets, wall brackets, condensate pumps, double-storey work) add time/cost.
- Ducted: Needs suitable roof/cavity space and careful design; more invasive.
Up Front & Servicing Costs
- Split: Typical installation from roughly $600–$1,500 for standard back-to-back (unit price not included; complexity can push costs higher).
- Ducted: Significantly higher capex due to ducts, zoning hardware and electricals; plan for regular filter/return maintenance.
Running Costs
-
Splits are usually cheaper to run when you only cool/heat the space you’re using (no duct losses). Ducted can make sense for simultaneous whole-home comfort with good zoning. For real world numbers, use the Energy Rating Calculator and your local tariff.
Quick comparison table
|
Factor |
Split (single/multi) |
Ducted |
|
Coverage |
One room / several zones (multi) |
Whole-home |
|
Install |
Back-to-back can be very simple |
Roof space, ducts, returns, zoning |
|
Up-front cost |
$600–$1,500 install (typical back-to-back) |
Much higher |
|
Running cost |
Low when conditioning one/two rooms |
Can be higher if many zones left on |
|
Noise |
Very quiet indoors; check dB(A) on label |
Quiet indoors; outdoor fan/compressor |
|
Best use-case |
Bedrooms, studies, lounges, small offices |
Families wanting house-wide comfort |
Split System Aircon Installation Cost
For a standard back-to-back install (indoor on an external wall; outdoor unit directly outside), expect about $600–$1,500 for labour/materials. Costs rise with:
- Long line-sets or tricky access (double-storey, roof runs)
- Wall brackets or concrete pads
- Condensate pump (if gravity drain not possible)
- Switchboard upgrades/circuits and compliance certificates
- Core drilling through masonry or special finishes
These ranges come from national trade pricing roundups and installer guides. Get a firm quote based on photos or a site visit.
Mini quote-checklist (copy/paste into your enquiry): room size (L×W×H), wall type, indoor unit position, distance to outdoor location, storey level, meter board photo, desired install date, any body-corp/strata rules, parking/access notes.
Compliance reminder: Refrigerant work must be done by an ARC-licensed tech, and electrical works by appropriately licensed electricians (varies by state).
Split System Aircon Running Costs & Power Consumption
How to Read the Zoned Energy Rating Label (ZERL)
The ZERL shows:
- Stars (up to 10) for heating and cooling in hot / average / cold climates.
- Estimated annual kWh by climate zone (blue for cooling, red for heating).
- Indoor & outdoor noise indicators in dB(A) at the bottom left—handy for bedrooms and neighbours.
Suggested visual callout: “How to read the label” box with a labelled ZERL image and bullet legend (Stars, kWh/yr, Climate Zone, dB(A)).
A Worked Example (cooling)
- Find the kWh/year figure for your climate on the label or the Energy Rating Calculator.
- Multiply by your electricity tariff: Annual cost = kWh × $/kWh.
Example: If your label (average zone) shows 320 kWh/yr and your tariff is $0.30/kWh, your cooling cost is ~$96/yr. Use the official calculator to compare models.
What do Aussies Actually pay?
Based on Canstar Blue’s analysis (4 hrs/day over 13 weeks), typical yearly cooling costs range from about $50 to $583, depending on capacity and settings.
Best Split System Aircon for a Bedroom
For most bedrooms, look at ~2.0–2.5 kW cooling capacity (confirm with a room-size/load calculator or your installer). Shading and insulation are more accurate than simple “m² only” rules.
Bedroom-friendly features to prioritise:
- Low indoor noise (check the ZERL dB(A) figure)
- Sleep mode and fine fan speed steps for gentler airflow
- Wi-Fi/app control for schedules and timers
- Good filters you can clean easily (monthly if used daily in summer)
Energy efficient split system aircon what to look for:
- Inverter compressor for smoother, more efficient operation.
- Higher star ratings on the ZERL yes, some models now hit 10-star in certain zones.
- Right-sizing: too big, short-cycles; too small struggles. Use a reputable calculator (e.g., FairAir) or ask your installer to size it properly.
- Thermostat set-points: set cooling around the mid-20s; every 1 °C higher can trim ~5–10% off cooling. Use ceiling or pedestal fans (only a few cents per hour) to feel cooler at a higher set-point.
- Refrigerant: modern splits commonly use R32 (lower GWP than R410A) under Australia’s updated refrigerant rules.
Wall Mounted Split System Aircon Placement
- Indoor head high on a solid wall, central to the zone, with clear throw and no direct sun.
- Outdoor unit on stable ground or wall brackets with clear airflow and service space; avoid hot west walls if possible.
- Use the label’s dB(A) to plan for quiet outcomes (e.g., bedroom or neighbour windows).
Suggested visual: placement diagram indicating height, throw, clearance, drain path and outdoor setbacks.
Split System Aircon Maintenance
Regular maintenance keeps efficiency high and protects your manufacturer warranty.
At Home:
- Clean filters, if you use the aircon daily, about monthly in summer; lighter use every 3 months.
- Keep indoor and outdoor coils clean and unobstructed; trim vegetation around the condenser.
- Check condensate drains for blockages before peak season.
Pro Service:
- Book a yearly service (or as per usage) for coil cleaning, electrical checks, refrigerant tests, and a general health check.
- Many brands offer 5 year parts & labour warranties in Australia, but they generally require licensed installation and proper care.
- Some brands explicitly state warranty is void if not installed by a licensed ARCtick professional.
Quick Maintenance Table (Save This):
- Filters: inspect monthly in peak season; clean if dusty
- Outdoor coil area: clear debris quarterly
- Drains: check before summer/winter
- Pro service: annually (pre-summer or pre-winter)
How to Choose: Quick Decision Tree
- Room size & layout: shortlist capacity (e.g., 2.0–2.5 kW for many bedrooms; verify with calculator/installer).
- Budget: weigh unit price + installation (is your job back-to-back or complex?).
- Noise: check ZERL dB(A) for indoor and outdoor.
- Efficiency: compare stars and kWh/yr in your climate zone; prefer inverter, higher stars, R32 refrigerant.
- Lead time & installer: book an ARC-licensed installer; confirm electrical scope and any body-corp approvals.
Geo-/Answer Engine Boosters (What We’ve Included)
- FAQ Page schema-ready Q&As
- A clear TL;DR summary section
- Comparison table (split vs ducted)
- Label reading explainer with kWh/yr and noise dB(A)
- Worked running-cost example + links to Energy Rating Calculator and Fair Air Canstar
FAQs
How does a split system aircon work?
Is a split system cheaper to run than ducted?
What size split system do I need for a bedroom?
How much does split system installation cost?
What are typical yearly running costs?
What’s the Zoned Energy Rating Label (ZERL)?
What temperature should I set in summer?
Are fans worth using with a split?
Which brands rate well in Australia?
Wall-mounted vs multi-split?
Size it Right, Install it Right, And Keep it Running Right
A well-chosen split system can deliver quiet, efficient comfort for bedrooms, studies and living areas, without the complexity or cost of ducts. Compare stars and kWh/yr on the ZERL, right-size your capacity, plan a clean install (ideally back-to-back), and keep filters tidy for low bills and long life. For tricky floor plans or whole-home comfort, weigh up multi-split or ducted with zoning.
